1> High Quality indoor led module wholesale and OEM customized
2> Easy to splicing 16:9 ratio
3> Small spacing, easy to do 2K, 4K Ultra HD led screen
4> Full front maintemance without space needed for backside
5> Multiple installation way, DIY nunique shape.
Hotline
+86 400-0755-223
Application
Used in nightbar,DJ booth, commercial advertising led sign, retail shop, shopping mall and ect.
LED Module Parameters
| Pxiel Pitch | 6mm |
| Pixels Density | 40000 dots/㎡ |
| led Encapsulation | 3 in 1 (1R1G1B), SMD2121 or SMD3528 |
| Module resolution | 32*32 dots |
| Module size | 192*192mm |
| Available cabinet size | 576*576mm, 768*768mm |
| Viewing Angle | H140° V130° |
| Best viewing distance | >= 6m |
| Working Voltage & Current | AC 110V-220V, ≤5A |
| Working temperature & Humidity | -20℃-40℃, 10%RH -65%RH |
| Max power consuption | 650W/㎡ |
| Average power consuption | 200W/㎡ |
| Scanning Mode | 1/16 scan |
| Drive Type | constant drive |
| Brightness wite balance | 1700 cd/sqm |
| Refresh Frequency | 1920HZ or 3840HZ opetional |
| Port | HUB75E |
Pixel Pitch: 6.0mm
Module Size: 192*192mm
Resolution: 32*32 dots
LED: SMD3528
Brightness: ≥1000nits
Max Current: ≤5A
Pixel Density: 27777 dots/㎡
Refresh Rate: ≥ Q-PRO 3840Hz | Q-E 1920HZ
Port: HUB75E
